•    Operating Frequency Band: 2~18GHz (Customizable);

•     Receiving Instantaneous Bandwidth: 12GHz;

•     Jamming Instantaneous Bandwidth: 1GHz

•     Sensitivity of Receiving System: ≤-65dBm;

•     Effective Range Reception:≥150km

•     Application Profile: Conducting team jamming against ground  guidance and airborne fire control radar;

•     Effective Radiated Power: ≥10W (Customizable);

•     Antenna Beam Width: ≥90° ×60° (Customizable);

•    Jamming  Mode: Noise jamming, Deception jamming and  Combined jamming;

•     Communication Mode: Communication through the target link,  RS 422 interface;

•     Power Consumption: ≤200W;

•     Endurance Time: ≥45min (powered by battery).
