SSPV20k PV-ESS Technical Specification

Product Features:
Ø    Excellent Safety:
High-safety battery cells with comprehensive certifications
No circulation between clusters, enhancing safety and system efficiency
Rational insulation measures, eliminating short-circuit risks between clusters
Ø    Long Lifespan:
 Intelligent air-cooling system for extended lifespan and minimal footprint
15-year lifespan under standard operating conditions
Ø    Flexible Expansion:
Supports the addition of parallel machines for future expansion
Pre-designed interfaces for integrated use with fuel storage equipment
Ø    Ease of Use:
Integrated delivery and installation for convenient deployment
Modular design simplifies maintenance

1.Overview

Designed to address power shortages in areas with limited or unreliable grid access, as wellas in the aftermath of grid disruptions, the SSPV20k Photovoltaic and Storage System (SSPV20kPV-ESS)provides daily power support and emergency energy for military facilities, ensuring the uninterrupted operation of critical systems such as communication and command. Additionally, it optimizes the military's energy supply structure, reducing reliance on fuel and other logistical resources, thereby lightening the logistical burden and enhancing the efficiency and reliability of logistical support.



Figure 1: SSPV20K Photovoltaic and Storage System


Application:

Ø  Areas without grid access or with poor grid stability

Mountainous regions, islands, borders, etc.

Ø  Vital military defense zones

Camps, sentry posts, and key units


Product Features:

Ø  Excellent Safety:

·        High-safety battery cells with comprehensive certifications

·        No circulation between clusters, enhancing safety and system efficiency

·        Rational insulation measures, eliminating short-circuit risks between clusters

Ø  Long Lifespan:

·        Intelligent air-cooling system for extended lifespan and minimal footprint

·        15-year lifespan under standard operating conditions

Ø  Flexible Expansion:

·        Supports the addition of parallel machines for future expansion

·        Pre-designed interfaces for integrated use with fuel storage equipment

Ø  Ease of Use:

·        Integrated delivery and installation for convenient deployment

·        Modular design simplifies maintenance


2.Technical Specifications

1Photovoltaic Parameters

Maximum Power   (Pmax/W)

560W

Open-Circuit Voltage   (Voc/V)

50V

Short-Circuit   Current (isc/A)

14.14A

Module Efficiency

21.68%

Operating Voltage   (Vmp/V)

42.33V

Weight

28.6Kg

Operating Current   (Imp/A)

13.23A

Dimensions

2278mm x 1134mm x   35mm

2Battery Parameters

Model Number

LFP48100-5kWh

Rated Capacity

5.12kWh

Battery Type

LFP

Maximum Continuous   Charging Current

100A

Voltage

51.2Vdc

Maximum Continuous   Discharging Current

100A

Maximum Continuous   Discharging Voltage Range

44Vdc - 56.8Vdc

Peak Current

120A ≤ 0.3sec

Rated Current

100Ah

Protection Level

IP30

Charging Voltage

56.8Vdc

Short-Circuit   Current

440A, 500μs

3Inverter Output

Rated Power

10000W

Maximum Peak Power

15000W

Rated Output Voltage

230Vac   (Single-phase/Three-phase)

Motor Load Capacity

6HP

Rated AC Frequency

50Hz/60Hz

Waveform

Pure Sine Wave

Switching Time

100ms (Typical)

4System Specifications

Input   Voltage Range

UPS170~280Vac APL90~280Vac

Frequency   Range

50Hz/60Hz

Bypass   Overload Current

40A

MPPT   Tracking Efficiency

99.9%

Maximum   Battery Inversion Efficiency

95%

Dimensions

498*410*201mm

Weight

10.8kg

Operating   Temperature Range

10℃ to -55℃

Noise

60dB

Cooling   Method

Air-cooled

Warranty

1 year

Safety

IEC 62109, SAA

EMC

EN61000


3.System Load Capacity


Single   Device Power Consumption (W)

Quantity

Total Power   Consumption of Multiple Devices (W)

Daytime Working   Hours (h)

Nighttime Working   Hours (h)

Daily Consumption   (Wh)

Nighttime   Consumption (Wh)

Lights

15

10

150

2

8

300

1200

Drones

60

2

120

2

1

240

120

Refrigerators

85

10

850

12

12

10200

10200

Computers

150

8

1200

8

2.5

9600

3000

Rice Cookers

800

4

3200

0.5

0.5

1600

1600

Microwaves

1000

4

4000

0.5

0.5

2000

2000

Air Conditioners

1100

8

8800

2

2

17600

17600

Military Electrical   Equipment

500

2

1000

12

4

12000

4000

Total   Power Consumption



19320




39720


4.Composition

Serial Number

Module Name

Specification

Quantity

Remarks

1

Photovoltaic Panels

560w

36


2

Batteries

LFP 5.12kwh

8


3

Inverters

10kW

2

Supports grid/diesel generator input

4

Photovoltaic Combiner Boxes

BR2-2

2


5

Connectors

MC4

1


6

Matching Cables


1 set
