9-11GHz Horn Antenna TX-LB-9/11GHz-G16

Product Features:
Ø    High Energy Density
small size with large capacity for easy portability.
Ø    Ruggedness and Durability
Capable of withstanding impacts, shocks, water, and dust, ensuring stable operation in harsh environments.
Ø    Strong Compatibility
Offers multiple output interfaces and voltage options, supporting a wide range of communication devices, drones, night vision goggles, GPS, and more
Ø    Intelligent Management
Integrated smart power management system for real-time monitoring of battery level and temperature, with overcharge and over-discharge protection to extend battery life.
Ø    Mobile Charging
Equipped with an XT60 interface for connecting to solar panels for on-the-go charging.

1.1    Overview

     The 9~11GHz horn antenna, designated as TX-LB-9/11GHz-G16, is designed for the reception and transmission of radio frequency signals within the 9 to 11GHz range.


1.2    Technical Specifications

    1)   Frequency: 9~11GHz;

    2)   Antenna Type: Horn antenna;

    3)   Antenna Gain:  16dB;

    4)   Beamwidth:  15°× 32° ;

    5)   VSWR (Voltage Standing Wave Ratio):  2.0;

    6)   Polarization: Horizontal polarization;

    7)   Input Port: Type N.
