Multi-sensor Pod Equipment (YADC190)

OPTOELECTRONIC PRODUCTS

Home > Products > OPTOELECTRONIC PRODUCTS

Product Features:
Ø High Safety:
Equipped with high-safety batteries and comprehensive certifications; no circulation between clusters enhances safety and system efficiency; effective insulation measures prevent short-circuit risks.
Ø Long Lifespan:
Features an intelligent air-cooling system, resulting in a long lifespan and minimal footprint. Standard operating conditions ensure a 15-year lifespan.
Ø Flexible Expansion:
Supports the addition of parallel units for future expansion. Designed withinterfaces for integration with oil storage equipment.
Ø Ease of Use:
One-stop delivery and installation, convenient layout; modular design simplifies maintenance.

INQUIRY NOW

1.1 Overview

The YADC190 Multi-sensor pod is an all-weather optoelectronic reconnaissance device that integrates visible light cameras, medium-wave infrared imaging, and laser rangefinders. It is designed for reconnaissance surveillance, target tracking, and ranging functions.

1.2 Technical Specifications

1) Frequency Band: X-Band; Visible Light 0.4μm to 0.9μm, Infrared 3μm to 5μm;

2) Detection and Recognition Distances:

Detection Distance:

≥3KM (for a target of 0.4m×0.4m DJI Phantom drone);

≥8KM (for a target of 3m×6mvehicle);

Recognition Distance:

≥2KM (for a target of 0.4m×0.4m DJI Phantom drone);

≥4KM (for a target of 3m×6m vehicle);

3) Ranging Accuracy: ±3m;

4) Dimensions: Φ410mm×580mm;

5) Weight: ≤50kg.
