Electronic Reconnaissance Capability Parameters:

•Frequency Range: 2～18GHz;

•Instantaneous Operating Bandwidth: ≥1GHz;

•Receiving Sensitivity: Better than -75dBm;

•Coverage: Horizontal: ≥270°; Vertical: ≥60°;

•Direction-finding Accuracy: ≤2° (R.M.S).

System Parameters:

•Wingspan: 4800mm;

•Length: 2580mm;

•Endurance: ≥2 hours;

•Cruising Speed: 100km/h~120km/h;

•Maximum Flying Speed: 150km/h;

•Practical Ceiling: 4500m.

After takeoff, the electronic warfare reconnaissance aircraft follows the designated route into the reconnaissance area to perform signal acquisition and interception. The route is safe from enemy fire and can be repeated. The aircraft's receiver is highly sensitive, allowing it to intercept weak enemy signals from long distances more effectively than ground or maritime platforms, especially in high-alert situations.
